No.

Model

ZCNQ100X8

ZCNQ100X10

ZCNQ100X12

ZCNQ100X6

ZCNQ100X20

1

Dia. of liquid inlet tube

￠219mm

￠219mm

￠219mm

￠219mm

￠219mm

2

Dia. Of overflow tube

￠219mm

￠219mm

￠219mm

￠219mm

￠219mm

3

Quantity of cyclone

8Pc

10Pc

12Pc

16Pc

20Pc

4

Nominal Dia. Of cyclone

￠100mm

￠100mm

￠100mm

￠100mm

￠100mm

5

Material of cyclone

Red polyurethane

Red polyurethane

Red polyurethane

Red polyurethane

Red polyurethane

6

Diameter of underflow tap

￠18

￠18

￠18

￠18

￠18

7

Separation size

15-40μm

15-40μm

15-40μm

15-40μm

15-40μm

8

Operating pressure

0.25-0.35Mpa

0.25-0.35Mpa

0.25-0.35Mpa

0.25-0.35Mpa

0.25-0.35Mpa

9

Handling capacity

140m3/h

140m3/h

140m3/h

140m3/h

140m3/h

10

Specification of vibration motor

VLB30154-W

VLB30154-W

VLB30154-W

VLB30154-W

VLB30154-W

11

Power of vibration motor

0.5Kw

0.5Kw

0.5Kw

0.5Kw

0.5Kw

12

Specification of screen cloth

1800X600

1800X600

1800X600

1800X600

1800X600

13

Meshes of screen cloth

160mesh

160mesh

160mesh

160mesh

160mesh

14

Overall dimension

1670X1050X1750

1670X1050X1750

1670X1050X1750

1670X1050X1750

1670X1050X1750

15

Weight of complete machine

730kg

760kg

790kg

850kg

910kg
